SPE Vacuum Manifold (Negative Pressure)

High-Efficiency Sample Preparation for Reliable Extraction

Althea Solutions introduces the SPE Vacuum Manifold, a robust and precision-engineered system specifically designed for efficient and reliable solid phase extraction (SPE) sample preparation. Built to handle complex sample matrices, the system utilizes controlled vacuum pressure to ensure consistent flow rates and effective analyte isolation, enabling accurate and reproducible results for analytical applications.

Equipped with a user-friendly design, individual flow control, and high-throughput capability, the SPE Vacuum Manifold delivers efficient performance for sample clean-up, concentration, and extraction processes. Designed for continuous operation, the system is ideal for environmental testing, pharmaceutical analysis, food testing, and research laboratories.

Available in multiple configurations with different sample capacities, the SPE Vacuum Manifold supports flexible workflows and high-performance sample preparation.

Enquire Now
Download Brochure

Description

Key Features

High Throughput Processing

Available in 12, 24, and 48 position configurations for simultaneous sample handling.

Individual Flow Control

Each port is equipped with stopcocks for precise control of flow rates.

Vacuum-Assisted Operation

Supports vacuum range up to 0–20 inches Hg for efficient extraction.

Universal Compatibility

Compatible with standard Luer-tipped SPE cartridges and filtration columns.

Transparent Glass Chamber

Allows easy visual monitoring of sample processing.

Adjustable Rack System

Accommodates various tubes, vials, and flasks for flexible usage.

Additional Technical Highlights

Individual flow control stopcocks for each position

Vacuum gauge for monitoring pressure

Extremely low due to non-mechanical operation

Removable rack for easy sample handling

Female Luer inlets for universal compatibility

Durable construction with chemical-resistant materials

Designed for high reproducibility and minimal sample loss

Applications

Environmental Analysis: Used for extraction and concentration of analytes from water and soil samples.
Pharmaceutical Testing: Supports sample preparation for drug analysis and quality control.
Food & Beverage Testing: Ensures removal of interfering substances for accurate testing.
Research & Academic Laboratories: Ideal for chromatographic sample preparation and analytical studies.

Product Models & Specifications

Model	Capacity	Configuration Description	Vacuum Pump Specification	Accessories Included
ALH SVM-12 S	12 Port	12 position manifold with Luer fittings	Flow: 25 LPM, Max Vacuum: 22" Hg, 25 PSI	Flask (1L), Tubing (2 m), Pump
ALH SVM-24 S	24 Port	24 position manifold with Luer fittings	Flow: 45 LPM, Max Vacuum: 27" Hg, 55 PSI	Flask (1L), Tubing (2 m), Pump
ALH SVM-48 S	48 Port	48 position manifold with Luer fittings	Flow: 45 LPM, Max Vacuum: 27" Hg, 55 PSI	Flask (1L), Tubing (2 m), Pump

Note: All models include glass chamber, vacuum gauge, retaining clips, flow control stopcocks, and required fittings for operation.

Trusted Performance, Certified Quality

Althea Solutions’ SPE Vacuum Manifolds are manufactured under strict quality standards, delivering accurate and consistent sample preparation. Designed for precision, efficiency, and ease of use, these systems ensure reliable performance across modern laboratory and analytical applications.

Why Choose Althea Solutions’ Karl Fischer Moisture Titrator?

1. Accurate Results: Ensures reliable sample preparation with controlled flow
2. High Efficiency: Processes multiple samples simultaneously
3. User-Friendly Design: Easy setup and operation with adjustable components
4. Flexible Configurations: Available in multiple capacities for varied needs
5. Robust Construction: Built for long-term laboratory use
6. Reliable Operation: Consistent performance for critical analytical workflows
