Microprocessor Dissolution Test Apparatus

High-Precision Tablet Dissolution Testing System

Althea Solutions introduces the Microprocessor Dissolution Test Apparatus, a robust and precision-engineered system specifically designed for accurate determination of dissolution rates of pharmaceutical tablets and capsules. Built in compliance with USP and IP standards, the system ensures reliable, repeatable, and controlled testing conditions for quality control and research laboratories.

Equipped with a microprocessor-based control system, graphical display interface, and programmable operation modes, the apparatus delivers precise control over stirring speed, temperature, and test parameters. Designed for ease of use and consistent performance, the system is ideal for pharmaceutical labs, research institutions, and formulation development environments.

Available in standard and touchscreen variants, the apparatus supports multiple programmable setups, data storage, and external connectivity—ensuring efficient and uninterrupted testing workflows.

Enquire Now
Download Brochure

Description

Key Features

USP & IP Compliance

Designed as per pharmaceutical standards for accurate dissolution testing.

Microprocessor Control System

Ensures precise control of speed, temperature, and test parameters.

Programmable Stirrer Speed

Adjustable speed range from 25 to 200 RPM with high accuracy.

Graphical / Touchscreen Display

Available with graphical LCD display or 7-inch touchscreen interface for easy operation.

Multiple Programming Modes

Supports Routine, Sustain, and Control modes for flexible testing.

Data Storage & Connectivity

Stores up to 400 samples with USB interface and printer connectivity.

Additional Technical Highlights

Stations

8 basket system

Speed Accuracy

±1 RPM

Temperature Accuracy

±1°C

Temperature Control

Microprocessor-based with PT100 sensor

Programming Modes

Routine, Sustain, Control

Setup Storage

Up to 20–40 programmable methods

Data Storage

Up to 400 test samples

Power Supply

230V ±10%, 50 Hz

Operation

Continuation of test in case of power failure

Applications

Pharmaceutical Testing: Used for dissolution testing of tablets and capsules in QC and R&D labs.
Formulation Development: Supports drug release studies and product development processes.
Quality Control Laboratories: Ensures batch consistency and compliance with regulatory standards. Quality Control Laboratories: Ensures batch consistency and compliance with regulatory standards.
Research & Academic Labs: Widely used for analytical studies and dissolution profiling.

Product Models & Specifications

Model	Display	Stations	Speed Range	Temperature Range	Storage
ALH DTA-721	Graphical LCD	8 Basket	25–200 RPM	30–50°C	400 Samples
ALH DTA-7210	7” Touchscreen	8 Basket	25–200 RPM	30–50°C	400 Samples

Note: Both models include programmable modes and printer connectivity. Touchscreen variant offers enhanced user interface and control.

Trusted Performance, Certified Quality

Althea Solutions’ Microprocessor Dissolution Test Apparatus is manufactured under strict quality standards, delivering reliable and accurate dissolution testing performance. Engineered for precision, ease of use, and durability, the system ensures consistent results for pharmaceutical and research applications.

Why Choose Althea Solutions’ Karl Fischer Moisture Titrator?

1. Accurate Results: Ensures precise and repeatable dissolution testing.
2. Easy Operation: User-friendly interface with programmable controls.
3. Reliable Performance: Stable system with consistent temperature and speed control.
4. Flexible Configuration: Available in standard and touchscreen models.
5. Data Management: Built-in storage and connectivity for better workflow.
6. Backed by Warranty: Includes a 1-Year Manufacturer’s Warranty
